Bag Filter Dust Collector
YT-01MC
Pulse Jet Bag Filter Dust Collector
The workhorse for high-volume, high-temperature and heavy dust loads.
- Model series
- YT-01MC48 – YT-01MC300
- Air volume
- 2,000 – 25,000 m³/h
- Fan power
- 5.5 – 45 kW
- Filter bags
- 48 – 300 per unit
- Cleaning
- On-line pulse jet, 1" valves
- Housing
- Carbon steel, custom thickness
- CE certified · ISO 9001 manufacturer
- 12-month warranty on main equipment
- Custom size, material and colour
Overview
A pulse-jet baghouse sized for continuous industrial duty. Compressed-air pulses clean the bags on-line, so the unit keeps a low, stable pressure drop through the shift instead of slowly choking. Media can be specified for heat, moisture, abrasion or static.
- Set into the stiffened panels of the housing, the rectangular access doors provide the service openings for the collector. Each door is fastened around its rim and seals against the panel, keeping the casing airtight while the unit runs. During a maintenance stop, an operator opens a door to inspect the bags and the internal walls, then fastens it closed again within minutes. The doors are positioned so that the areas needing the most attention are reached without removing panels.
- Built from carbon steel with stiffened panels and a protective paint finish, the casing stays rigid under continuous suction. A wide flanged inlet gives the site ducting a firm, sealed connection, and three inverted-pyramid hoppers collect the released dust and discharge it evenly through flanged outlets. Access doors on the housing allow quick inspection of the bags.
- The same collector design can control dust in many different processes, including metal grinding and polishing, stone cutting and grinding, grain and feed processing, foundry sand handling, powder packing and sandblasting. For each application the unit is selected to match the dust load, and the flanged inlet connects simply to the workshop ducting.
- Every machine can be supplied to your specification. Body color can be blue, white, gray, green or any shade you choose; supply voltage can be 380V, 400V or 480V; overall size follows your workshop; air volume matches the working condition; and the nameplate can carry your logo. Since the factory handles customization directly, details are confirmed before production and the machine arrives ready to run.
- Every collector is manufactured and supplied directly by the factory and passes a quality check before shipment, covering welding, paint, fasteners and the cleaning system. Our team guides installation and answers technical questions after the machine is running.
Key advantages
-
On-line pulse cleaning
Bags are cleaned row by row while the fan keeps running, so extraction never stops for a cleaning cycle.
-
Media matched to your dust
Polyester, anti-static polyester, fibreglass, PPS, aramid and PTFE-membrane bags — chosen for your temperature, humidity and chemistry.
-
Serviced from the top
Bags and cages lift out through the clean-air plenum. No confined-space entry into the dirty side.
-
Built to your drawing
Inlet position, hopper angle, discharge type, platform and ladder, plate thickness and paint colour are all specified per order.
See it running
Technical data
Model specifications
Full range as manufactured. Sizes and configurations outside this table are built to order.
| Model | Filter Bags(Quantity) | Fan | Air Volume m³/h | Quantity of Pulse Valves | Dimensions mm |
|---|---|---|---|---|---|
| YT-01MC64 | 64 | 5.5 kW | 5712-10562 | 8 | 1550*1550*4200 |
| YT-01MC80 | 80 | 7.5 kW | 7725-12000 | 8 | 1550*2160*4400 |
| YT-01MC96 | 96 | 11kW | 7725-12000 | 12 | 2220*1860*4400 |
| YT-01MC120 | 120 | 15kW | 9000-12000 | 12 | 2220*2160*4400 |
| YT-01MC140 | 140 | 18.5 kW | 8000-15640 | 14 | 2560*2160*4400 |
| YT-01MC200 | 200 | 22 kW/30 kW | 15000-18000 | 20 | 3800*2160*4800 |
| YT-01MC300 | 300 | 37 kW/45 kW | 19404-25000 | 30 | 5500*2160*4800 |
| YT-01MC500 | 500 | 55 kW/75 kW | 30000-40000 | 50 | 9500*2160*5000 |
-
YT-01MC64
Filter Bags(Quantity) 64
Fan 5.5 kW
Air Volume 5712-10562 m³/h
Quantity of Pulse Valves 8
Dimensions 1550*1550*4200 mm
-
YT-01MC80
Filter Bags(Quantity) 80
Fan 7.5 kW
Air Volume 7725-12000 m³/h
Quantity of Pulse Valves 8
Dimensions 1550*2160*4400 mm
-
YT-01MC96
Filter Bags(Quantity) 96
Fan 11kW
Air Volume 7725-12000 m³/h
Quantity of Pulse Valves 12
Dimensions 2220*1860*4400 mm
-
YT-01MC120
Filter Bags(Quantity) 120
Fan 15kW
Air Volume 9000-12000 m³/h
Quantity of Pulse Valves 12
Dimensions 2220*2160*4400 mm
-
YT-01MC140
Filter Bags(Quantity) 140
Fan 18.5 kW
Air Volume 8000-15640 m³/h
Quantity of Pulse Valves 14
Dimensions 2560*2160*4400 mm
-
YT-01MC200
Filter Bags(Quantity) 200
Fan 22 kW/30 kW
Air Volume 15000-18000 m³/h
Quantity of Pulse Valves 20
Dimensions 3800*2160*4800 mm
-
YT-01MC300
Filter Bags(Quantity) 300
Fan 37 kW/45 kW
Air Volume 19404-25000 m³/h
Quantity of Pulse Valves 30
Dimensions 5500*2160*4800 mm
-
YT-01MC500
Filter Bags(Quantity) 500
Fan 55 kW/75 kW
Air Volume 30000-40000 m³/h
Quantity of Pulse Valves 50
Dimensions 9500*2160*5000 mm
Component layout
Need a CAD file or a general-arrangement drawing for your bid documents? Request it here — we send them on request.
Questions
What buyers ask before ordering
If your question is not here, ask it in the form — an engineer answers, not a salesperson.
-
How do I know which model fits my workshop?
Tell us the total air volume you need, or list your extraction points and duct diameters and we will calculate it. If you only know the workshop area and the process, that is enough for a first sizing.
-
What air-to-cloth ratio do you design your equipment to?
It depends on the dust. Fine, sticky or hygroscopic dust needs a lower ratio than coarse wood dust. We size the filter area from your dust type rather than applying one value to every installation.
-
Can it handle hot gases?
Yes, with the right filter media. Standard polyester is limited to about 130 °C continuous; glass fibre and PPS go considerably higher. Send us your gas temperature and we will specify the media and the housing.
-
What compressed air supply does it need?
The unit needs clean, dry compressed air for the pulse valves. We state the required pressure and consumption on the quotation for your model.
-
Do you also supply the fan and the ducting?
Yes. We can supply the collector on its own, or the collector with a matched fan, ducting, hoods, screw conveyor and control panel as a complete system.
-
What is the lead time?
It depends on the model and configuration. Typical production lead time is 20–45 days, and we confirm the exact delivery date on the quotation.
-
How often do the filter bags need replacing?
Service life depends on the dust and the running hours. A typical range is 6–24 months; aggressive, hot or abrasive dust shortens it. By default we ship only a few spare bags with the unit — not a full set of replacement bags; further spare bags must be requested explicitly on the order and are charged separately.
-
What warranty do you offer?
The main equipment carries a 12-month warranty on materials and workmanship. Consumables such as filter media are wearing parts: apart from confirmed manufacturing defects, they are not covered by warranty after normal use.
-
Do you help with installation?
Yes. Every order includes installation manuals, and our engineers support your local fitters by video call during commissioning. For complete-line projects we also advise on the duct layout before installation.
