Welding Fume Extractor
YT-HYSB / YT-HYGB
Effective Fume Extraction for Welding and Metal Processing
Capture the fume at the arc, before it reaches the welder.
- Model series
- YT-HYSB1 / HYSB2 / HYGB1 / HYGB2
- Air volume
- 2,500 – 3,500 m³/h
- Fan power
- 1.5 – 3 kW
- Filter area
- 5 – 10 m²
- Suction arm
- 1.2 m arm, 160 × 2000/3000 mm
- Weight
- 60 – 110 kg
- CE certified · ISO 9001 manufacturer
- 12-month warranty on main equipment
- Custom size, material and colour
Overview
A wheeled cartridge filter with a self-supporting articulated arm. Position the hood near the arc and the fume is captured at source rather than being diluted into the workshop. Single- and twin-arm versions cover one or two welding stations.
- In metal processing industries such as steel fabrication, automotive manufacturing, shipbuilding, and machinery production, processes like welding, laser cutting, grinding, and polishing are widely applied. These operations are essential for shaping and assembling metal components but continuously generate fumes and fine airborne particles. Both robotic welding lines and manual workstations operate simultaneously, requiring effective air filtration systems to ensure stable production and a safe working environment.
- During welding processes (MIG, TIG, CO2), large amounts of submicron metal fumes are generated, containing harmful substances such as iron, manganese, chromium, and nickel oxides, along with toxic gases like ozone (O3) and nitrogen oxides (NOx). Laser cutting and plasma cutting produce high-temperature smoke mixed with fine dust, while grinding and polishing release airborne particles and sparks. These pollutants can easily enter the human respiratory system, causing long-term health issues, reducing productivity, and increasing risks of fire and explosion
- To solve these problems, a high-efficiency Fume Extractor is required. With flame-retardant filters, spark arrestors, and multi-stage filtration such as HEPA and activated carbon, it can remove over 99.9% of fine particles. Flexible extraction arms capture fumes directly at the source, preventing diffusion. For larger workshops, centralized systems can collect emissions from multiple stations, ensuring clean air, regulatory compliance, and safer production conditions.
- Our Fume Extractor is designed for industrial applications, offering up to 99.9% filtration efficiency for fine fumes. Equipped with flame-retardant filters and spark protection, it ensures safe operation. The 360° flexible extraction arm allows precise source capture, while the compact and mobile design enables easy use in different workstations. With low noise, energy-saving performance, and easy maintenance
Key advantages
-
Capture at source
An arm positioned at the arc removes fume before it reaches the breathing zone. General ventilation only dilutes it.
-
The arm stays put
The articulated arm is self-supporting — set it once and it holds position through the weld instead of drifting.
-
Moves between stations
The wheeled cabinet rolls to wherever today's work is. No installation, no ducting.
-
One or two welders
Single-arm HYSB for one station, twin-arm HYGB with double the filter area for two.
See it running
Technical data
Model specifications
Full range as manufactured. Sizes and configurations outside this table are built to order.
| Model | Air Volume | Fan | Filter Cartridge (Qty.) | Filter Area | Suction Arm | Suction Arm Size mm | Weight kg | Dimensions mm |
|---|---|---|---|---|---|---|---|---|
| YT-HYSB1 | 2500m³/h | 1.5kW | 1Φ325×500mm | 5m² | 2m | 160×2000 | 60 | 500×700×1000 |
| YT-HYSB2 | 3000m³/h | 2.2kW | 1Φ325×500mm | 5m² | 2m | 160×2000 | 65 | 500×700×1000 |
| YT-HYGB1 | 3000m³/h | 2.2kW | 2Φ325×500mm | 10m² | 2m | 160×2000 | 100 | 750×800×1200 |
| YT-HYGB2 | 3500m³/h | 3kW | 2Φ325×500mm | 10m² | 3m | 160×3000 | 110 | 750×800×1200 |
-
YT-HYSB1
Air Volume 2500m³/h
Fan 1.5kW
Filter Cartridge (Qty.) 1Φ325×500mm
Filter Area 5m²
Suction Arm 2m
Suction Arm Size 160×2000 mm
Weight 60 kg
Dimensions 500×700×1000 mm
-
YT-HYSB2
Air Volume 3000m³/h
Fan 2.2kW
Filter Cartridge (Qty.) 1Φ325×500mm
Filter Area 5m²
Suction Arm 2m
Suction Arm Size 160×2000 mm
Weight 65 kg
Dimensions 500×700×1000 mm
-
YT-HYGB1
Air Volume 3000m³/h
Fan 2.2kW
Filter Cartridge (Qty.) 2Φ325×500mm
Filter Area 10m²
Suction Arm 2m
Suction Arm Size 160×2000 mm
Weight 100 kg
Dimensions 750×800×1200 mm
-
YT-HYGB2
Air Volume 3500m³/h
Fan 3kW
Filter Cartridge (Qty.) 2Φ325×500mm
Filter Area 10m²
Suction Arm 3m
Suction Arm Size 160×3000 mm
Weight 110 kg
Dimensions 750×800×1200 mm
Component layout
Need a CAD file or a general-arrangement drawing for your bid documents? Request it here — we send them on request.
Questions
What buyers ask before ordering
If your question is not here, ask it in the form — an engineer answers, not a salesperson.
-
How far does the arm reach?
The standard arm is 1.2 m. Longer arms and wall-mounted versions are available — tell us your station layout.
-
Single arm or twin arm?
One arm per welder working at the same time. Two welders operating simultaneously need the twin-arm HYGB, which also carries double the filter area.
-
Does it handle stainless steel welding fume?
Yes. Stainless fume is finer and more hazardous, so we recommend the higher filter area and a suitable cartridge grade.
-
Can the filtered air be returned to the workshop?
In many cases yes, which saves heating in cold climates. Whether recirculation is permitted depends on the material being welded and your local regulations.
-
How often do cartridges need changing?
It depends on duty hours and process. Pulse cleaning extends life considerably. We quote spare cartridges with the machine so the running cost is visible up front.
